Minimum Order Quantity: 2 pieces
Prix: CN¥26,383.86-35,656.37/pieces
private mold: |
NO |
products status: |
Stock |
type: |
Rack |
processor main frequency: |
3.4GHz |
processor type: |
intel xeon |
model number: |
R860 |
place of origin: |
Beijing, China |
Model NO.: |
R860 server |
Hard Drive:: |
3.84TB SSD vSAS 12Gbps 512e RI 2.5in Hot-Plug |
Specification: |
2U rack server |
Raid: |
Front PERC H355 Rear Load |
Processor Main: |
3.4GHz |
RAID Controller: |
H345 h745 h755 raid card |
size:: |
707mm*482mm*86.8mm |
Fans: |
Standard/Up to 6 sets hot plug fans |
private mold: |
NO |
products status: |
Stock |
type: |
Rack |
processor main frequency: |
3.4GHz |
processor type: |
intel xeon |
model number: |
R860 |
place of origin: |
Beijing, China |
Model NO.: |
R860 server |
Hard Drive:: |
3.84TB SSD vSAS 12Gbps 512e RI 2.5in Hot-Plug |
Specification: |
2U rack server |
Raid: |
Front PERC H355 Rear Load |
Processor Main: |
3.4GHz |
RAID Controller: |
H345 h745 h755 raid card |
size:: |
707mm*482mm*86.8mm |
Fans: |
Standard/Up to 6 sets hot plug fans |
Processor | Up to four 4th Generation Intel Xeon Scalable processor with up to 60 cores per processor and with optional Intel® QuickAssist Technology |
Memory | • 64 DDR5 DIMM slots, supports RDIMM 16 TB max, speeds up to 4800 MT/s • Supports registered ECC DDR5 DIMMs only |
Storage controllers | • Internal Controllers: PERC H965i, PERC H755, PERC H355, HBA355i • External Controller: PERC H965e • Internal Boot: Boot Optimized Storage Subsystem (BOSS-N1): HWRAID 2 x M.2 NVMe SSDs or USB • External HBA (non-RAID): HBA355e • Software Raid: S160 |
Drive Bays | Front bays: • Up to 8 x 2.5-inch SAS/SATA (HDD/SSD) drives max 122.88 TB • Up to 8 x EDSFF E3.S Gen5 NVMe (SSD) drives max 61.44TB • Up to 16 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) drives max 245.76 TB • Up to 24 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) drives max 368.34 TB • Up to 16 x 2.5-inch SAS/SATA (HDD/SSD) drives + 8 x 2.5-inch NVMe (SSD) drives max 368.34 TB Rear bays: • Up to 2 x2.5-inch SAS/SATA (HDD/SSD) drives max 30.72 TB • Up to 4 x EDSFF E3.S Gen5 NVMe (SSD) drives max 30.72 TB |
GPU Options | 2 x 75 W SW, LP |
Hot swap Redundant Power Supplies | • 1100 W Titanium 100—240 VAC or 240 HVDC, hot swap redundant • 1400 W Platinum 100—240 VAC or 240 HVDC, hot swap redundant • 1800W Titanium 200—240 VAC or 240 HVDC, hot swap redundant • 2400 W Platinum 100—240 VAC or 240 HVDC, hot swap redundant • 2800 W Titanium 200—240 VAC or 240 HVDC, hot swap redundant |
Cooling Options | • Air cooling |
Fans | • Standard (STD) fans • Up to 6 sets hot plug fans |
Dimensions | • Height – 86.8 mm (3.41 inches) • Width – 482 mm (18.97 inches) • Depth – 883.2 mm (34.77 inches) with bezel 869.2 mm (34.22 inches) without bezel |
Form Factor | 2U rack server |
Embedded Management | • iDRAC9 • iDRAC Direct • iDRAC RESTful API with Redfish • iDRAC Service Module • Quick Sync 2 wireless module |
Bezel | Optional LCD bezel or security bezel |
OpenManage Software | • CloudIQ for PowerEdge plug in • OpenManage Enterprise • OpenManage Enterprise Integration for VMware vCenter • OpenManage Integration for Microsoft System Center • OpenManage Integration with Windows Admin Center • OpenManage Power Manager plugin • OpenManage Service plugin • OpenManage Update Manager plugin |
Mobility | OpenManage Mobile |
Embedded NIC | 2 x 1 GbE LOM |
