Détails du produit
Conditions de paiement et d'expédition
Minimum Order Quantity: 2 pieces
Prix: CN¥19,258.29/pieces >=2 pieces
products status: |
Stock |
type: |
Rack |
processor main frequency: |
2.4GHz |
processor type: |
/ |
model number: |
R960 |
place of origin: |
Beijing, China |
Memory: |
2.4TB *16 |
RAM Slots: |
24 |
Drive Bays: |
8 x 2.5'' SAS/SATA/SSD |
Form Factor: |
4U Rack Server |
Storage Controller: |
P48I-A |
Weight: |
30kg |
Warranty: |
3 Years |
Power Supply: |
1600W*2 |
Hard Drive: |
32Gb *24 |
products status: |
Stock |
type: |
Rack |
processor main frequency: |
2.4GHz |
processor type: |
/ |
model number: |
R960 |
place of origin: |
Beijing, China |
Memory: |
2.4TB *16 |
RAM Slots: |
24 |
Drive Bays: |
8 x 2.5'' SAS/SATA/SSD |
Form Factor: |
4U Rack Server |
Storage Controller: |
P48I-A |
Weight: |
30kg |
Warranty: |
3 Years |
Power Supply: |
1600W*2 |
Hard Drive: |
32Gb *24 |
Feature | Technical Specifications | ||
Processor | Up to four 4th Generation Intel Xeon Scalable processor with up to 60 cores per processor and with optional Intel® QuickAssist Technology | ||
Memory | • 64 DDR5 DIMM slots, supports RDIMM 16 TB max, speeds up to 4800 MT/s • Supports registered ECC DDR5 DIMMs only | ||
Storage controllers | • Internal Controllers: PERC H965i, PERC H755, PERC H355, HBA355i • Internal Boot: Boot Optimized Storage Subsystem (BOSS-N1): HWRAID 2 x M.2 NVMe SSDs or USB • External HBA (non-RAID): HBA355e • Software RAID: S160 | ||
Drive Bays | Front bays: • Up to 8 x 2.5-inch SAS/SATA (HDD/SSD) max 122.88 TB • Up to 16 x 2.5-inch SAS/SATA (HDD/SSD) max 245.76 TB • Up to 24 x 2.5-inch NVMe (SSD) max 368.64 TB • Up to 16 x 2.5-inch SAS/SATA (HDD/SSD) + 8 x 2.5-inch NVMe (SSD) max 368.64 TB • Up to 32 x 2.5-inch SAS/SATA (HDD/SSD) max 491.52 TB | ||
Power Supplies | • 1100 W Titanium 100—240 VAC or 240 HVDC, hot swap redundant • 1400 W Platinum 100—240 VAC or 240 HVDC, hot swap redundant • 1800 W Titanium 200—240 VAC or 240 HVDC, hot swap redundant • 2400 W Platinum 100—240 VAC or 240 HVDC, hot swap redundant • 2800 W Titanium 200—240 VAC or 240 HVDC, hot swap redundant | ||
Cooling Options | • Air cooling • Optional Direct Liquid Cooling (DLC)* Note: DLC is a rack solution and requires rack manifolds and a cooling distribution unit (CDU) to operate. | ||
Fans | • Standard (STD) fans • Up to 6 sets (dual fan module) hot plug fans | ||
Dimensions | • Height – 174.3 mm (6.86 inches) • Width – 482 mm (18.97 inches) • Depth – 883.195 mm (34.77 inches) with bezel 869.195 mm (34.22 inches) without bezel | ||
Form Factor | 4U rack server | ||
Embedded Management | • iDRAC9 • iDRAC Direct • iDRAC RESTful API with Redfish • iDRAC Service Module • Quick Sync 2 wireless module | ||
Bezel | Optional LCD bezel or security bezel | ||
OpenManage Software* | • CloudIQ for PowerEdge plug in • OpenManage Enterprise • OpenManage Enterprise Integration for VMware vCenter • OpenManage Integration for Microsoft System Center • OpenManage Integration with Windows Admin Center • OpenManage Power Manager plugin • OpenManage Service plugin • OpenManage Update Manager plugin | ||
Mobility* | OpenManage Mobile | ||
OpenManage Integrations* | • BMC Truesight • Microsoft System Center • OpenManage Integration with ServiceNow • Red Hat Ansible Modules • Terraform Providers • VMware vCenter and vRealize Operations Manager | ||
Security | • Cryptographically signed firmware • Data at Rest Encryption (SEDs with local or external key mgmt) • Secure Boot • Secure Erase • Secured Component Verification (Hardware integrity check) • Silicon Root of Trust • System Lockdown (requires iDRAC9 Enterprise or Datacenter) • TPM 2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ | ||
Embedded NIC | 2 x 1 GbE LOM card (optional) | ||
Network options | 1 x OCP card 3.0 (optional) Note: The system allows either LOM card or an OCP card or both to be installed in the system. | ||
GPU Options | Up to 4 x 400 W DW |
